Established in 2010, Infonet Solutions is a leading manufacturer of Reverse PoE Switch for solving a major problem of powering the device for Internet Services Providers on last mile buildings. Infonet Solutions has a strong focus on R&D and local manufacturing which specializes in design, development and customizations of wired and wireless solutions especially for Internet Service Providers. We have different solutions for Wireless Networks, Fiber Networks as well as FTTH. Our goal is to provide superior products whice save time and money of Internet Service Providers. Our Products are designed for India, specifically keeping in mind our operating environment. Our products are RELIABLE. We provide excellent pre-sales and post-sales support to customer all over india. We have many more products coming to reduce your cost of operation and per user expenses…
Technical Specifications of Netstar Reverse PoE Switch
Reverse PoE Technology Power Over Ethernet Feature
Siwitch has Intelligent Power management feature solving a major problem of powering the device for ISPs.This switch can be powered using remote Power from customer end using Special designed reliable NETMODEM from us or ant standard PoE Injector (24V DC, 0,75 AMP).This eliminates the need to arrange for power at building top and no UPS needed/no money to be paid to society/power providing customer.This save lot of MONEY for ISPs and improves service Delivery with uninterrupted service to the customer.
Over Current Protection
If for any reason, PoE Out port cable is shorted / water ingress in PoE OUT Cable going to Wireless CPE, Heavy current may flow in PoE OUT Port. We have provided Over current protection by way of resettable fuse which can prevent damage to the switch power management circuit / tracks on the PCB by limiting current and opening the circuit if current flows for longer time. Resettable fuse will not require replacement of the same as it will open the circuit temporarily and if short circuit is temporary in nature, it may go away and switch can function normally. If it is not of temporary nature, this fuse will blow preventing serious damage to the switch.
Port Based Isolation: Port Based Vlan
The feature of Port Isolation is implemented in this Unit where in the Ethernet Data of the Uplink Port can be transferred to any of the Downlink ports but the individual Downlink ports cannot communicate with each other. This feature is implemented using Port based VLAN.
Each PoE IN port is feeding Power to the Power management circuit of the switch. It is designed to withstand surges occurring due to transient voltages induced while connecting / disconnecting RJ45 connectors as well as Stray Induced voltages on Copper Cables (Especially during Monsoon ).
Over Voltage Protection
Provided Over voltage protection on each PoE IN Port. Even if by mistake, field engineer connects PoE which is more than 24V (say 48V), switch has enough protection built-in to prevent damage to the switch and switch will go in OFF Mode. Protection is available up to 50V.
